Four-in-one Screw Type Air Compressor-132KW
This 132kW bipolar permanent magnet variable frequency screw air compressor is a high-end energy-saving equipment specially developed for large industrial gas demand. It integrates two-stage compression technology, high-efficiency permanent magnet synchronous motor and intelligent variable frequency control system. It can provide 26.5m³/min of large flow compressed air, and the working pressure is stably maintained at 0.8MPa. It is an ideal power source for modern factories.
Send Inquiry
Product Introduction
| Core technical advantages: 1. Efficient two-stage compression system: adopts optimized two-stage compression main engine, equipped with large-capacity intercooler, and the compression efficiency is increased by more than 18% compared with single stage. The unique rotor profile design ensures that the large flow air of 26.5m³/min can be stably output at a working pressure of 0.8MPa, and the volumetric efficiency is as high as 98.5%. 2. Ultra-high efficiency permanent magnet motor: Equipped with 132kW energy efficiency grade permanent magnet synchronous motor, using high temperature resistant NdFeB permanent magnet material, full load efficiency reaches 97%, and efficiency remains above 94% at 50% load. The motor and host adopt direct connection design, and the transmission efficiency is close to 100% 3. Intelligent control system: Equipped with a new generation of intelligent variable frequency drive system, it can achieve 30%-100% stepless speed regulation and pressure control accuracy of ±0.01MPa. Built-in intelligent joint control module can manage multiple devices at the same time to achieve the most optimized group control operation. Product features: - The whole machine noise is controlled within 86dB(A), which meets strict industrial environment standards - Equipped with a three-level high-efficiency filtration system, the air quality meets the standard - Real-time display of energy efficiency data and operating status - Support industrial Internet of Things remote monitoring to achieve predictive maintenance - Key components use international first-line brands with a design life of more than 100,000 hours |
| Machine Model | Power KW | Noise db (A) | Exhaust volume(m³/min 0.8Mpa) | Outlet pipe diameter | Overall dimensions | Weight KG |
| Four-in-one screw type air compressor-132KW | 132 | 83±3 | 26.5 | Dn80 | 3500*1900*2000 | 3600 |
Hot Tags: four-in-one screw type air compressor-132kw, China four-in-one screw type air compressor-132kw manufacturers, suppliers, factory
