Smart VSD Screw Air Compressor
Products Description
Key Features
1. Advanced VSD variable frequency system, automatically adjust air flow according to actual demand, greatly cut electricity cost.
2. High efficiency screw rotor, stable air output, low vibration and low running noise.
3. Intelligent PLC control panel, real-time display of working parameters, easy operation & fault alarm.
4. Air-cooled structure, strong heat dissipation, works reliably in high-temperature tropical areas like Venezuela.
5. Widely compatible consumable parts, convenient for local maintenance and spare part replacement.
6. Multiple pressure options: 7bar / 8bar /10bar /13bar for different industrial applications.
Application
Laser cutting, plastic blow molding, packaging, mining, mechanical processing and compressor repair service companies.
Our Advantage & Service
- Custom logo & OEM service available.
- Complete export documents for South America market.
- We can supply full set of filter, oil separator and lubricant together with the machine.
Technical parameter
| Model | Air Delivery(m3 /min) | Power (kw) |
Noise (Db) |
Outlet diameter | Dimension(mm) | Weight (kg) |
|||||
| 0.7Mpa | 0.8Mpa | 1.0Mpa | 1.2Mpa | L | W | H | |||||
| 10A | 1.2 | 1.1 | 0.95 | 0.8 | 7.5 | 66 | G1/2 | 880 | 670 | 880 | 200 |
| 15A | 1.65 | 1.5 | 1.3 | 1.1 | 11 | 68 | G3/4 | 1080 | 750 | 1000 | 340 |
| 20A | 2.5 | 2.3 | 2.1 | 1.72 | 15 | 68 | G3/4 | 1080 | 750 | 1000 | 350 |
| 25A | 3.2 | 3.0 | 2.7 | 2.4 | 18.5 | 68 | G1 | 1280 | 850 | 1160 | 500 |
| 30A | 3.8 | 3.6 | 3.2 | 2.7 | 22 | 68 | G1 | 1280 | 850 | 1160 | 500 |
| 40A | 5.3 | 5.0 | 4.5 | 4.0 | 30 | 69 | G1-1/2 | 1400 | 1000 | 1290 | 650 |
| 50A | 6.8 | 6.2 | 5.6 | 5.0 | 37 | 69 | G1-1/2 | 1400 | 1000 | 1290 | 650 |
| 60A | 7.4 | 7.0 | 6.2 | 5.6 | 45 | 72 | G1-1/2 | 1400 | 1000 | 1290 | 750 |
| 75A | 10.0 | 9.6 | 8.5 | 7.6 | 55 | 72 | G2 | 1680 | 1100 | 1440 | 1000 |
| 100A | 13.4 | 12.6 | 11.2 | 10.0 | 75 | 72 | G2 | 1800 | 1230 | 1570 | 1200 |
| 125A | 16.2 | 15.0 | 13.8 | 12.3 | 90 | 72 | G2 | 1890 | 1230 | 1570 | 1250 |
| 150A | 21.0 | 19.8 | 17.4 | 14.8 | 110 | 72 | G2-1/2 | 2280 | 1470 | 1840 | 2000 |
| 175A | 24.5 | 23.2 | 20.5 | 17.4 | 132 | 75 | G2-1/2 | 2280 | 1470 | 1840 | 2100 |
| 200A | 28.7 | 27.6 | 24.6 | 21.5 | 160 | 75 | G2-1/2 | 2560 | 1580 | 1920 | 3500 |
| 250A | 32.0 | 30.4 | 27.4 | 24.8 | 185 | 75 | DN80 | 2560 | 1580 | 1920 | 3600 |
| 300A | 36.0 | 34.3 | 30.2 | 27.7 | 220 | 82 | DN80 | 3600 | 2100 | 2200 | 4800 |
| 350A | 42.0 | 40.5 | 38.2 | 34.5 | 250 | 82 | DN80 | 3600 | 2100 | 2200 | 4900 |
| 430A | 51.0 | 50.2 | 44.5 | 39.5 | 315 | 82 | DN80 | 3800 | 2200 | 2300 | 6000 |
| 480A | 64.0 | 61.0 | 56.5 | 49 | 355 | 84 | DN100 | 4600 | 2240 | 2260 | 6500 |
